| Basic Information | ||
| Supported CPU | LGA1700 socket: Support for 12th Generation Intel Core, Pentium Gold and Celeron Processors<br> L3 cache varies with CPU | |
| Chipset | Intel H610 Express Chipset | |
| BIOS | 1 x 256 Mbit flash<br> Use of licensed AMI UEFI BIOS<br> PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
| Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm | |
| Audio | Realtek Audio CODEC<br> High Definition Audio<br> 2/4/5.1/7.1-channel<br> * To configure 7.1-channel audio, you need to open the audio software and select Device <br>advanced settings > Playback Device to change the default setting first. | |
| Expansion Slots | ||
| PCI | 1 x PCI Express x16 slot, running at x16<br> (The PCIEX16 slot conforms to PCI Express 4.0 standard.)<br> 2 x PCI Express x1 slots<br> (The PCIEX1 slots conform to PCI Express 3.0 standard.) | |
| Memory Specifications | ||
| Type | DDR4 | |
| Slots | 4 x DDR DIMM sockets | |
| Supported Memory | Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ <br>4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / <br>4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / <br>3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200/3000/2933/2666/2400/2133 MHz memory <br>modules<br> Dual channel memory architecture<br> Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)<br> Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules<br> Support for Extreme Memory Profile (XMP) memory modules | |
| Max. Memory | up to 128 GB (32 GB single DIMM capacity) of system memory | |
| Graphics | ||
| Graphics | Integrated Graphics Processor-Intel HD Graphics support:<br> 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz<br> 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz<br> * Support for HDMI 2.1 version and HDCP 2.3.<br> ** Support native HDMI 2.1 TMDS compatible ports.<br> 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz<br> * Support for DisplayPort 1.2 version and HDCP 2.3<br> 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz<br> * Support for DisplayPort 1.2 version.<br> Support for up to 4 displays at the same time | |
| Connector & Ports | ||
| HDMI | 1 x HDMI port | |
| USB (s) | 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support<br> 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB <br>header)<br> 2 x USB 2.0/1.1 ports on the back panel<br> Chipset+2 USB 2.0 Hubs:<br> 4 x USB 2.0/1.1 ports available through the internal USB headers | |
| LAN Port (s) | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) | |
| Supported Storage | CPU:<br> 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)<br> Chipset:<br> 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)<br> 4 x SATA 6Gb/s connectors<br> Support for RAID 0, RAID 1, RAID 5, and RAID 10<br> Intel Optane Memory Ready | |
| Audio | 3 x audio jacks | |
| Internal I/O Ports | 1 x 24-pin ATX main power connector<br> 1 x 8-pin ATX 12V power connector<br> 1 x CPU fan header<br> 3 x system fan headers<br> 1 x addressable LED strip header<br> 1 x RGB LED strip header<br> 2 x M.2 Socket 3 connectors<br> 4 x SATA 6Gb/s connectors<br> 1 x front panel header<br> 1 x front panel audio header<br> 1 x USB 3.2 Gen 1 header<br> 2 x USB 2.0/1.1 headers<br> 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)<br> 1 x serial port header<br> 1 x parallel port header<br> 1 x S/PDIF Out header<br> 1 x Q-Flash Plus button<br> 1 x reset button<br> 1 x reset jumper<br> 1 x Clear CMOS jumper | |
| D-Sub (s) | 1 x D-Sub port | |
| Others Information | ||
| Special Features | Support for APP Center<br> * Available applications in APP Center may vary by motherboard model. Supported functions <br>of each application may also vary depending on motherboard specifications.<br> @BIOS<br> EasyTune<br> Fast Boot<br> Game Boost<br> ON/OFF Charge<br> RGB Fusion<br> Smart Backup<br> System Information Viewer<br> Support for Q-Flash Plus<br> Support for Q-Flash<br> Support for Xpress Install | |
| Warranty Information | ||
| Manufacturing Warranty | 3 years | |
The Gigabyte H610M S2H DDR4 12th Gen Micro ATX Motherboard is designed to deliver exceptional performance, stability, and reliability for modern computing needs. Compatible with Intel’s 12th generation processors, this motherboard supports DDR4 memory and offers enhanced data transfer speeds, making it ideal for both gaming and professional workloads. Its compact Micro ATX form factor allows for flexible PC builds without compromising on essential features. The motherboard comes equipped with multiple USB ports, PCIe slots, and M.2 support for high-speed storage devices, ensuring seamless connectivity and expandability. Users can expect advanced thermal design and durable components that provide long-lasting reliability, even under intensive workloads. Whether you are upgrading your current system or building a new PC, the Gigabyte H610M S2H ensures excellent performance, smooth multitasking, and future-ready compatibility.
Explore why the Gigabyte H610M S2H stands out among 12th Gen motherboards:
Whether upgrading your workstation or building a high-performance gaming PC, the Gigabyte H610M S2H provides unmatched value. For those looking for High-Performance 12th Gen Boards, this motherboard is a top choice in the 12th gen motherboard category. You can trust Speedtech for genuine products and reliable service, ensuring your PC build is future-ready and optimized for peak performance.
The latest price of Gigabyte H610M S2H DDR4 12th Gen Micro ATX Motherboard in Bangladesh is 12,500৳ You can buy the Gigabyte H610M S2H DDR4 12th Gen Micro ATX Motherboard at best price from our Website or visit any of our showrooms.
