Specification
| Basic Information |
| Supported CPU | AMD Socket AM5, support for: AMD Ryzen 8000 & 7000 Series Processors |
| Chipset | AMD B650 |
| BIOS | 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm |
| Audio | Realtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel |
| Expansion Slots |
| PCI | CPU:
1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
Chipset:
1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
| Memory |
| Type | DDR5 |
| Slots | 4 DIMMs |
| Supported Memory | Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MT/s memory modules
Dual channel memory architecture
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules |
| Maximum Memory | 192 GB |
| Graphics |
| Graphics | 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
* Support for DisplayPort 1.4 version.
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version and HDCP 2.3.
** Support native HDMI 2.1 TMDS compatible ports. |
| Connector & Ports |
| HDMI | 1x HDMI |
| Display Port (s) | 1 x DisplayPorts |
| USB (s) | CPU:
1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
2 x USB 2.0/1.1 ports on the back panel
Chipset:
1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header
4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) |
| LAN Port (s) | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Supported Storage | CPU:
1 x M.2 connector (Socket 3, M key, type 2580 PCIe 4.0 x4/x2 SSD support)
1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support)
Chipset:
4 x SATA 6Gb/s connectors |
| RAID | RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
| Audio | 3 x Audio jacks |
| Internal I/O Ports | 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
2 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
2 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C® header, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x reset jumper
1 x Clear CMOS jumper |
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) |
| Others |
| Special Features | Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
Support for Q-Flash
Support for Q-Flash Plus |
| Bundled Software | Norton Internet Security (OEM version)
LAN bandwidth management software |
| Warranty Information |
| Manufacturing Warranty | 3 Years |
GIGABYTE B650M K AMD AM5 Micro-ATX Motherboard
Planning to build a powerful next-gen PC but struggling to find a motherboard that balances performance, compatibility, and future-proof features? The GIGABYTE B650M K AMD AM5 Micro-ATX Motherboard is designed to eliminate those concerns by offering cutting-edge technology for gamers, creators, and PC enthusiasts. Built for AMD Ryzen 7000 and 8000 series processors, this motherboard delivers the performance and stability needed for modern computing. Equipped with the AMD B650 chipset and support for high-speed DDR5 memory up to 8000MHz (OC), the B650M K ensures lightning-fast responsiveness and smooth multitasking. Its PCIe 4.0 support allows you to take full advantage of high-performance GPUs and ultra-fast NVMe SSDs, making it perfect for gaming and content creation. With dual M.2 slots and multiple SATA ports, you get flexible storage options for your growing needs. Additionally, the motherboard features 2.5GbE LAN for faster and more stable networking, along with modern connectivity options including USB Type-C. The compact Micro-ATX form factor makes it ideal for space-saving builds without compromising on features. Whether you are upgrading or building a new system, the GIGABYTE B650M K is a reliable foundation for high-performance computing.
Key Benefits of GIGABYTE B650M K Motherboard
1. Future-Ready Performance with AM5 Platform: Designed to support AMD Ryzen 7000 and 8000 series CPUs, this motherboard ensures long-term usability and compatibility with next-generation processors.
2. High-Speed DDR5 Memory Support: With support for DDR5 RAM up to 8000MHz (OC), you get faster data processing, improved multitasking, and better system responsiveness for demanding applications.
3. Enhanced Gaming & Storage Performance: PCIe 4.0 support and dual M.2 slots allow for faster graphics performance and ultra-fast SSD speeds, reducing load times and improving overall gaming experience.
4. Reliable & Fast Network Connectivity: The built-in 2.5GbE LAN provides stable and high-speed internet connectivity, ideal for online gaming, streaming, and large file transfers.
5. Smart Features & Easy Management: With GIGABYTE Control Center, Q-Flash, and Q-Flash Plus, users can easily manage system settings, update BIOS, and optimize performance without hassle.
Why Choose GIGABYTE B650M K?
- Trusted Build Quality: GIGABYTE motherboards are known for durability, stability, and consistent performance under heavy workloads.
- Compact Yet Powerful Design: The Micro-ATX form factor offers excellent features in a space-saving size, perfect for modern PC builds.
- Advanced Connectivity & Expandability: With multiple USB ports, M.2 slots, and expansion options, it supports future upgrades easily.
Upgrade your PC build with the GIGABYTE B650M K motherboard from SpeedTech. Experience next-gen performance, faster speeds, and reliable stability. Order now at the best price in Bangladesh and build your dream PC today!
