MSI PRO H610M-E DDR5 Intel® H610 Chipset 14th/ 13th/ 12th Gen mATX Motherboard

Stock: In Stock
Brand: MSI
Model: PRO H610M-E

Based on 1 reviews. - Write a review

10,800৳

Ex Tax: 10,800৳

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

* অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে *

Key Features

- Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
- Supported RAM: 2x DDR5, Max 96GB
- Graphics Output: 1x HDMI, 1x VGA
- Features: 1x M.2 slot, Realtek RTL8111H Gigabit LAN

View more details

Basic Information
Supported CPU	Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors LGA 1700
Chipset	Intel H610 Chipset
Form Factor	mATX 200mmx236.16mm
Audio	Realtek ALC897 Codec 7.1-Channel High Definition Audio
Type	DDR5
Expansion Slots
PCI	1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to (From CPU) PCI_E2 Gen PCIe 3.0 supports up to (From Chipset)
Memory Specifications
Slots	2
Supported Memory	Memory Support DDR5 5600 MHz (by JEDEC & POR) Supports Intel XMP 3.0 OC Supports Dual-Controller Dual-Channel mode Supports non-ECC, un-buffered memory
Maximum Memory	96GB
Graphics
Graphics	Support HDMI 1.4 with HDR, maximum resolution of 4K 30Hz Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
Connector & Ports
HDMI	1x HDMI 1.4 with HDR port
USB (s)	4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front)
LAN Port (s)	Realtek RTL8111H Gigabit LAN
Supported Storage	1x M.2 M.2_1 Source (From Chipset) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G SATA5 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.
Audio	1x Front panel audio connector
Internal I/O Ports	1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports
TPM (Trusted Platform Module )	1x TPM pin header(Support TPM 2.0)
VGA (s)	1x VGA
Others Information
Special Features	1x 4-pin RGB LED connector 4x EZ Debug LED
Warranty Information
Warranty	3 years

MSI PRO H610M-E DDR5 Intel® H610 Chipset 14th/ 13th/ 12th Gen mATX Motherboard

The MSI PRO H610M-E DDR5 motherboard is a dependable and efficient solution designed for users looking to build a modern, high-performance PC with the latest Intel processors. Powered by the Intel® H610 chipset, it supports 14th, 13th, and 12th Gen Intel Core®, Pentium Gold, and Celeron processors, making it a versatile foundation for both productivity and everyday computing. Built in the compact mATX form factor, this motherboard offers an optimal balance of features and space-saving design, making it ideal for home, office, or budget-friendly builds without compromising reliability. Equipped with DDR5 memory support up to 96GB, the PRO H610M-E allows higher bandwidth and improved system responsiveness. Its dual-channel architecture and support for Intel XMP 3.0 ensure smooth multitasking and stable overclocking potential. The board includes a PCIe 4.0 x16 slot, offering the bandwidth needed for modern graphics cards, along with an additional PCIe 3.0 x1 slot for expansion flexibility. For storage, the motherboard features a PCIe 3.0 x4 / SATA M.2 slot and four SATA 6Gb/s ports—ideal for fast SSDs and additional hard drives. Connectivity is efficient with USB 3.2 Gen1 and USB 2.0 ports, along with Realtek RTL8111H Gigabit LAN for dependable networking. Integrated display options include HDMI 1.4 with HDR and VGA, providing support for a wide range of monitors. MSI enhances the user experience with useful tools such as EZ Debug LED, which simplifies troubleshooting, and a 4-pin RGB connector for customizable lighting. Designed for stability and long-term durability, the MSI PRO H610M-E DDR5 is a compact, feature-rich choice backed by a 3-year warranty, delivering excellent value for modern PC builds.

Features of MSI PRO H610M-E DDR5 Intel® H610 Chipset 14th/ 13th/ 12th Gen mATX Motherboard

CPU Support: Compatible with 14th, 13th, and 12th Gen Intel® Core™, Pentium Gold, and Celeron processors on the LGA1700 socket, delivering strong performance and excellent upgrade flexibility.
Chipset & Form Factor: Built with the Intel® H610 chipset on a compact mATX form factor (200mm x 236.16mm), ideal for efficient and space-saving PC builds.
Memory Performance: Supports DDR5 memory up to 96GB, featuring dual-channel architecture, Intel XMP 3.0 OC, and JEDEC-supported speeds up to 5600 MHz for fast and stable multitasking.
Expansion Slots: Equipped with 1x PCIe 4.0 x16 slot for modern graphics cards and 1x PCIe 3.0 x1 slot for additional expansion cards.
Graphics Output: Offers HDMI 1.4 with HDR (up to 4K at 30Hz) and VGA ports for versatile display connectivity, depending on CPUs with integrated graphics.
Storage Options: Includes 1x M.2 PCIe 3.0 x4 / SATA slot supporting 2280/2260/2242 SSDs, along with 4x SATA 6Gb/s ports for additional storage devices.
USB Connectivity: Features 2x USB 3.2 Gen1 and 4x USB 2.0 rear ports, plus 2x USB 3.2 Gen1 and 4x USB 2.0 front headers for flexible device support.
Audio Quality: Integrated Realtek ALC897 7.1-channel High Definition Audio ensures clear and immersive sound for daily use.
