MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard

Stock: In Stock
Brand: MSI
Model: B550M Pro-VDH WiFi

Based on 1 reviews. - Write a review

15,900৳

Ex Tax: 15,900৳

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

* অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে *

Key Features

- AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
- M.2 SHIELD FROZR
- Supports DDR4 4400+ (OC)
- PCB with 2OZ Thickened Copper

View more details

Basic Information
Supported CPU	AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
Chipset	AMD B550
Form Factor	Micro-ATX Form Factor 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
Expansion Slots
PCI	1x PCIe 4.0/ 3.0 x16 slot (PCI_E1) 2x PCIe 3.0 x1 slots
M.2 Socket	2x M.2 slots (Key M) M2_1 slot (from AMD Processor) Supports PCIe 4.0/ 3.0 x4 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices M2_2 slot (from AMD B550 chipset) Supports PCIe 3.0x4 Supports 2242/ 2260/ 2280 storage devices
Graphics
Graphics	1x VGA port, supports resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz 1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz
Max Shared Memory	16GB
Memory
Slots	4x DDR4 memory slots
Supported Memory	Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE 1DPC 1R max speed 4400 MHZ 1DPC 2R max speed 3733 MHZ 2DPC 1R max speed 3866 MHZ 2DPC 2R max speed 3466 MHZ Supports non-ECC UDIMM memory Supports ECC UDIMM memory Supports un-buffered memory
Type	Dual-channel memory architecture
Maximum Memory	128GB
Connector & Ports
HDMI	1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz
Display Port (s)	1x DisplayPort supports a maximum resolution of 4096x2160 @60Hz
USB (s)	AMD B550 Chipset 3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector) 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors) AMD Processor 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
LAN Port (s)	1x Realtek 8111HN Gigabit LAN controller
Supported Storage	AMD B550 Chipset 4x SATA 6Gb/s ports 2x M.2 slots (Key M) M2_1 slot (from AMD Processor) Supports PCIe 4.0/ 3.0 x4 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices M2_2 slot (from AMD B550 chipset) Supports PCIe 3.0x4 Supports 2242/ 2260/ 2280 storage devices
Audio	Realtek ALC892 Codec 7.1-Channel High Definition Audio
Internal I/O Ports	1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 4x SATA 6Gb/s connectors 2x M.2 slots (M-Key) 1x USB 3.2 Gen 1 5Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump fan connector 3x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Serial port connector 1x Chassis Intrusion connector 2x 4-pin RGB LED connectors 2x 3-pin RAINBOW LED connectors 1x Clear CMOS jumper
TPM (Trusted Platform Module )	1 x TPM module connector
Others Information
Special Features	WIRELESS LAN & BLUETOOTH: Intel Dual Band Wireless-AC 3168- Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) up to 433 Mbps speed. Supports Dual Mode Bluetooth 2.1,2.1+EDR,3.0,4.0,BLE,4.2
Warranty Information
Warranty	03 Years Warranty

MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard

The MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard is a dependable and well-balanced platform built for gamers, creators, and everyday PC users who want strong performance, modern features, and long-term reliability. Powered by the AMD B550 chipset, it supports AMD Ryzen 5000 Series, 4000G Series, and 3rd Generation Ryzen processors, making it an excellent choice for building or upgrading an AM4-based system. Designed in a compact Micro-ATX form factor (9.6 x 9.6 inches), this motherboard fits easily into smaller cases while still offering excellent expandability. It includes one PCIe 4.0/3.0 x16 slot for modern graphics cards and two PCIe 3.0 x1 slots for additional expansion cards. Storage performance is impressive, with two M.2 slots—one supporting PCIe 4.0 x4 for ultra-fast NVMe SSDs—and four SATA 6Gb/s ports for traditional drives. Memory support is a major strength, featuring four DDR4 DIMM slots with support for up to 128GB RAM. With A-XMP overclocking, memory speeds can reach 4400+ MHz, ensuring smooth multitasking, faster load times, and responsive system performance. For display output, the board offers HDMI 2.1, DisplayPort, and VGA, supporting up to 4K resolution at 60Hz. Connectivity is enhanced with built-in Intel Dual Band Wi-Fi and Bluetooth, along with Gigabit LAN for stable wired networking. Multiple USB 3.2 Gen 1, USB 2.0, and USB Type-C headers ensure excellent peripheral support. With Realtek ALC892 7.1-channel HD audio, durable components, RGB headers, and a 3-year manufacturing warranty, the MSI B550M Pro-VDH Wi-Fi delivers outstanding value for gaming and productivity builds.

Features Of MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard

Wide Ryzen CPU Compatibility: Supports AMD Ryzen 5000 Series, 4000G Series, and 3rd Generation processors, ensuring flexibility for upgrades and future-proof performance.
High-Speed Memory Support: Four DDR4 slots support up to 128GB RAM with overclocking speeds reaching 4400+ MHz, delivering smooth multitasking and faster system response.
Advanced Storage with M.2 Shield Frozr: Dual M.2 slots, including PCIe 4.0 x4 support, provide ultra-fast SSD performance while M.2 Shield Frozr helps keep drives cool and stable.
Robust Power & PCB Design: Built with a 2oz thickened copper PCB, improving heat dissipation, power stability, and overall durability for long-term use.
Integrated Wi-Fi & Bluetooth: Intel Dual Band Wireless-AC offers reliable Wi-Fi connectivity and Bluetooth support, reducing cable clutter and enhancing convenience.
Modern Connectivity Options: Includes HDMI 2.1, DisplayPort, USB 3.2 Gen 1, USB Type-C headers, and Gigabit LAN for versatile device compatibility.
Enhanced Audio & RGB Support: Realtek ALC892 7.1-channel HD audio ensures immersive sound, while RGB and RAINBOW LED headers allow easy lighting customization.
