| General | |
| Operating Conditions | -30 °C To 60 °C (-22 °F To 140 °F). Humidity 95% Or Less (Non-Condensing) |
| Power | Power Supply: 12 VDC ± 25% PoE: 802.3af, Class 3 Power Consumption And Current: 12 VDC, 0.4 A, Max. 5 W PoE: (802.3af, 36 V To 57 V), 0.20 A To 0.15 A, Max. 6.5 W Power Interface: Ø 5.5 Mm Coaxial Power Plug |
| Camera | |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Lens | Focal Length & FOV: 2.8 Mm: Horizontal FOV 111.6°, Vertical FOV 59.1°, Diagonal FOV 133.9° 4 Mm: Horizontal FOV 91.5°, Vertical FOV 46.1°, Diagonal FOV 109.8° 6 Mm: Horizontal FOV 56°, Vertical FOV 29.8°, Diagonal FOV 65.3° Lens Mount : M12 Focus: Fixed Aperture: F1.6 |
| Minimum Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux With IR |
| Others | Shutter Speed: 1/3 S To 1/100,000 S Slow Shutter: Yes Wide Dynamic Range: 120 DB Day & Night: IR Cut Filter Angle Adjustment: Pan: 0° To 355°, Tilt: 0° To 75°, Rotate: 0° To 355° |
| Physical Specification | |
| Weight | Approx. 497 G (1.1 Lb.) |
| Dimension | Camera Dimension: Ø 110.8 Mm × 84.7 Mm (Ø 4.4" × 3.3") Package Dimension: 135 Mm × 135 Mm × 110 Mm (5.3" × 5.3" × 4.3") |
| Warranty Information | |
| Warranty | 1 years |
