| General | |
| Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Power | Power Supply: 12 VDC ± 25%, PoE (802.3af Class3) Power Consumption: 12 VDC, 0.5A, Max. 6W PoE (802.3af, 37V To 57V), 0.2A To 0.1A, Max. 7.5W |
| Camera | |
| Image Sensor | 1/3" Progressive Scan CMOS |
| IR Distance | Up to 25 m IR range |
| Lens | Focal Length : 2.8 Mm @ F1.6: Horizontal FOV: 103°, Vertical FOV: 58°, Diagonal FOV: 123° 4 Mm @F1.6: Horizontal FOV: 83°, Vertical FOV: 45°, Diagonal FOV: 99° 6 Mm @F1.6: Horizontal FOV: 51°, Vertical FOV: 29°, Diagonal FOV: 58° 8 Mm @F1.6: Horizontal FOV: 39°, Vertical FOV: 22°, Diagonal FOV: 45° Lens Type : Fixed Focal Lens, 2.8, 4, And 6 Mm Optional |
| Minimum Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux With IR On |
| Others | Shutter Time: 1/3 S To 1/100,000 S Day & Night: IR Cut Filter Angle Adjustment: Pan: 0° To 360°, Tilt: 0° To 90°, Rotate: 0° To 360° |
| Video | Video Bit Rate: 32 Kbps To 8 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile Bit Rate Control: CBR/VBR Scalable Video Coding (SVC): H.264 And H.265 Encoding Region Of Interest (ROI): 1 Fixed Region For Mainstream And Sub-Stream |
| Physical Specification | |
| Weight | Camera: Approx. 420 G (0.9 Lb.) With Package: Approx. 700 G (1.5 Lb.) |
| INTERFACE | Communication Interface: 1 RJ45 10M / 100M Ethernet Interface On-Board Storage: Built-In Micro SD/SDHC/SDXC Slot, Up To 128 GB Reset Button: Yes |
| Dimension | Camera: Φ 70 × 155.03 Mm (Φ 2.8" × 6.1") Package: 216 × 121 × 118 Mm (8.5" × 4.8" × 4.7") |
| Warranty Information | |
| Warranty | 1 years |
