Gigabyte GA-H81M-S2PH Micro ATX Motherboard

Name: Gigabyte GA-H81M-S2PH Micro ATX Motherboard
Brand: Gigabyte
SKU: 25690
Price: 7900.00 BDT
Availability: OutOfStock
Rating: 5 (1 reviews)

Gigabyte GA-H81M-S2PH Micro ATX Motherboard

Stock: In Stock
Brand: Gigabyte
Model: GA-H81M-S2PH
SKU: 25690

Based on 1 reviews. - Write a review

7,900৳

Ex Tax: 7,900৳

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

* অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে *

Key Features

- Supports 4th Generation Intel Core processors
- GIGABYTE UEFI DualBIOS
- All solid capacitors design
- LAN with high ESD Protection

View more details

Basic Information
Supported CPU	Support for Intel Core i7 processors/Intel Core i5 processors/Intel® Core™ i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1150 package
Chipset	Intel H81 Express
BIOS	2 x 64 Mbit flash Use of licensed AMI EFI BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	Micro ATX Form Factor; 24.4cm x 18.0cm
Expansion Slots
PCI	1 x PCI Express x16 slot, running at x16 1 x PCI Express x1 slot 2 x PCI slots
Memory Specifications
Type	Dual channel memory architecture
Slots	2 x 1.5V DDR3
Supported Memory	Support for DDR3 1600/1333 MHz memory modules
Graphics
Graphics	Integrated Graphics Processor - Intel HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200 1 x HDMI port, supporting a maximum resolution of 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
Max Shared Memory	1 GB
Connector & Ports
HDMI	1 x HDMI port maximum resolution of 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
USB (s)	Up to 2 USB 3.0/2.0 ports on the back panel Up to 6 USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
LAN Port (s)	Realtek GbE LAN chip (10/100/1000 Mbit)
Supported Storage	2 x SATA 6Gb/s connectors (SATA3 0/1) supporting up to 2 SATA 6Gb/s devices 2 x SATA 3Gb/s connectors (SATA2 2/3) supporting up to 2 SATA 3Gb/s devices
Audio	Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 2 x SATA 6Gb/s connectors 2 x SATA 3Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB 2.0/1.1 header 1 x serial port header 1 x Clear CMOS jumper
D-Sub (s)	1 x D-Sub port maximum resolution of 1920x1200
Others Information
Special Features	Support for Q-Flash Support for Xpress Install Support for APP Center * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications. @BIOS EasyTune EZ Setup USB Blocker Support for ON/OFF Charge
Warranty Information
Manufacturing Warranty	03 Years

Gigabyte GA-H81M-S2PH Micro ATX Motherboard

The Gigabyte GA-H81M-S2PH Micro ATX Motherboard is a reliable and budget-friendly motherboard designed to support Intel’s 4th generation Core processors. Built on the Intel H81 chipset, this motherboard offers stable performance for everyday computing, gaming, and multimedia tasks. Its compact Micro ATX form factor makes it perfect for small to medium-sized PC builds, allowing users to maximize space without compromising on functionality. Equipped with DDR3 memory support, high-speed USB 3.0 ports, and SATA III connectivity, the GA-H81M-S2PH ensures smooth data transfer and efficient multitasking. Users can also benefit from Gigabyte’s Ultra Durable components, which enhance longevity and thermal performance. With integrated Intel HD graphics support, this motherboard is capable of handling casual gaming, HD video playback, and professional applications with ease. Its user-friendly BIOS interface and plug-and-play setup make installation simple even for first-time builders. Overall, the GA-H81M-S2PH is a versatile motherboard that balances performance, durability, and cost-effectiveness, making it an excellent choice for entry-level to mid-range PC systems.

Special Benefits of Gigabyte GA-H81M-S2PH Micro ATX Motherboard

The Gigabyte GA-H81M-S2PH Micro ATX Motherboard combines performance, durability, and ease of use in a compact design. Here’s why it stands out:

Supports Intel 4th Gen Processors – Compatible with Intel Core i7/i5/i3, Pentium, and Celeron processors.
Dual Channel DDR3 Memory Support – Up to 16GB for smooth multitasking and better system performance.
Ultra Durable Components – High-quality capacitors and PCB design ensure longer lifespan and stability.
Expansion Slots – One PCIe x16 and two PCIe x1 slots for graphics cards, sound cards, or other peripherals.
USB 3.0 and SATA III – Faster data transfer speeds for external drives and SSDs.
Integrated Intel HD Graphics Support – Ideal for HD video playback and casual gaming.
Compact Micro ATX Form Factor – Perfect for space-saving PC builds without compromising functionality.
Easy BIOS & Plug-and-Play Setup – Simplifies installation and system configuration.

This motherboard is perfect for users looking for a dependable, high-performance option without breaking the bank. Whether you are building a home office PC, a multimedia workstation, or a casual gaming rig, the GA-H81M-S2PH has the features to meet your needs. Explore more Latest Intel Motherboards in the gigabyte Intel motherboard category at SpeedTech to find the ideal motherboard for your setup.
